Description:

Specifications:

ENGINE & POWERTRAIN

• Engine Brand: Kawasaki®
• Engine Model: FX730V
• Horsepower: 22 HP
• Displacement: 726 cc (44.3 in³)
• Fuel Type: Gasoline
• Fuel Capacity: 5.1 gal / 19.3 L
• Drive System: Hydro-Gear® ZT-3200™ Commercial-Grade Transaxles
• Brake Type: Lever-activated parking brake
• Driver Position: Sit-on
• Forward Speed: Up to 8.5 mph / 13.7 kph
• Reverse Speed: Up to 4 mph / 6.4 kph

ELECTRICAL SYSTEM

• Battery Capacity: 300 CCA
• Battery Type: Lead Acid (Maintenance-Free)
• Battery Size: U1

CUTTING DECK

• Deck Size / Cutting Width: 60 in / 152.4 cm
• Deck Material: 7-gauge steel
• Deck Type: Fabricated – X-Factor® 3 deck
• Discharge Type: Side discharge
• Coverage/Hour: Up to 5.1 acres / 2.1 hectares
• Cutting Height Range: 1.5 in – 5 in (3.8 – 12.7 cm)
• Cutting Height Adjustments: Manual height adjustment with deck lift

WHEELS

• Front Tires: 13 x 6.5 in – 6 in
• Rear Tires: 22 x 10.5 in – 12 in

DIMENSIONS

• Assembled Weight: 958 lbs / 434.5 kg
• Overall Length: 79 in / 200.7 cm
• Width (Chute Up): 63.7 in / 161.8 cm
• Width (Chute Down): 74.8 in / 190 cm
